SURRON LIGHT BEE X Electric Dirt Bike 60v 40Ah battery (100km Range 75km/h Off Road Dirt Bike) 2024 Model
Motor Max Rotation 3,000 rpm: EEC Homologation
Cooling Forced Air
Controller FOC Sine Wave, 2 modes: Standard & Sport
Phase Current 450A
MCU, Max Working Temp 100ºC
Rated Voltage 60V DC
Output Power 3000W /Massive 6KW Power Output
Rated/Peak Torque 8.5 Nm/ 34.0 Nm
Transmission Ratio 1:7.6
Drives Belt & Chain
Battery Pack 60V 40 Ah Lithium,176 Panasonic cells
Charger/Time 10A/ 67.2 V/ 2.5 – 3.5 hrs
Dashboard IBN Negative LCD Display
Front/ Rear Lights LED
Chassis 6061 T4 & T6 Aluminium Alloy
Chassis Process Forged: by 6000 Ton pressure
Chassis Weight 7.8kg Mainframe,
Swingarm & Tail bracket
Front Suspension, Adjustable DNM Upside-Down Hydraulic
Shock Absorber
Rear Suspension, Adjustable DNM Shock Absorber,
with Intersect TR System
Wheels Aluminium Alloy: Spoked
Rims, Front & Rear 19 x 1.4”
Tyres, Front & Rear 70/100-19
Max Speed 75kph: EEC Homologation
Cruising Range 100kms @ 20kph
Front & Rear Brakes Bilateral, 4-piston calliper, hydraulic discs
Net Weight 58 kgs, including battery
Max. Load 100 kgs
Max. Climb-Ability / Angle 80%/ 35º ( 45ºwith accessory kit)
Bike Size 1,870 x 780 x 1,040mm
Wheelbase 1,230 mm
Minimum Ground Clearance 270 mm
Seat Height 810 mm
Axle Weight Distribution 24kg Front, 26kg Rear
The Light Bee X is your ultimate off-road companion, boasting Upgraded 4 Piston Brakes for supreme stopping power, a Removable and Swappable Premium 40AH Battery for endless fun, and a lightweight yet robust Aluminum construction that defies rust. Charge up in a flash with our included 10A Fast Charger, giving you the freedom to ride longer and harder, as you explore the wilderness with exhilarating speed.
Description
Since its awe-inspiring debut in 2016, the Sur-Ron Light Bee Dirt Bike has earned a fierce reputation, taking on conventional petrol bikes with unmatched ferocity. This global phenomenon is a force to be reckoned with, dominating the trails and thrilling riders with its 6KW Output Mid Motor, unleashing a whirlwind of power! Blaze through any terrain, conquering sand, hills, dirt, grass, and beyond, with ease and finesse.
The Light Bee X is your ultimate off-road companion, boasting Upgraded 4 Piston Brakes for supreme stopping power, a Removable and Swappable Premium 40AH Battery for endless fun, and a lightweight yet robust Aluminum construction that defies rust. Charge up in a flash with our included 10A Fast Charger, giving you the freedom to ride longer and harder, as you explore the wilderness with exhilarating speed.
Light Bee Key Features:
– 40AH Lithium Battery for relentless energy
– 20% Range Increase, cruising up to 75km @ 40km/h
– Massive 6KW Power Output for unmatched thrills
– Top Speed reaching an exhilarating 75km/h
Grab the reins of this electrifying marvel and ignite your passion for adventure with the Surron Light Bee X Electric Dirt Bike – the ultimate off-road experience awaits!
Remember, this adrenaline-packed beast is strictly for OFF ROAD USE ONLY – it’s not your average street-legal bicycle. But fear not, whether you’re an outdoor enthusiast, trailblazer, farmer, or weekend warrior, the Surron Light Bee is the ideal ride for adventurers of almost all ages!
SURRON LIGHT BEE X
SPEED & RANGE
- Range LBX 75km (Cruising @40km/h)
- Top Speed 75km/h (L1E can be limited to 50km/h for Moped Registration)
BATTERY
- LBX 60V / 2,400Wh, 40AH
- Battery is removable and can be charged in bike or separately
RIDE MODES
- Mode 1 Eco mode: The ultimate mode energy conservation exploration
- Mode 2 Sport mode: Maximum torque and speed
FEATURES
- Hill Ability Up to 80% Inclines
- Horn Included
- USB Port Included
- Lights Front LED & Rear Tail Light (Always On – No Off Switch)
- Fenders Rear Only (Attached to Seat)
- Warranty 1 Year
BRAKES
- Front and Rear Bilateral 4-piston hydraulic disc, 203mm with Electric Regenerative Braking
CHARGING
- 3-4hrs with 10A Fast Charging
DISPLAY
- LCD Multi-Function (ODO, Trip, Battery, Speed, Top Speed etc)
CONTROLLER
- FOC Sine Wave X Controller
DRIVETRAIN
- Electric Motor BLDC Mid Motor
- Transmission Belt & Chain – Ratio 1: 7.6
- Rated Power 3 kW
- Peak Power 6 kW
- Max Torque 250 N·m
- Throttle Fly by Wire Twist
CONSTRUCTION
- Frame 6061 T4 & T6 Forged Aluminium Frame
- Handlebars 6061 aluminium, 780mm length
SUSPENSION
- Front KKE or Fastace Upside Down Fork Hydraulic Absorber with 200mm travel
- Rear KKE or Fastace Adjustable with Intersect TR, 87mm travel
WHEELS & TYRES
- Rims F&R 19×1.4″ Aluminium Spoke Wheels
- Tyres F&R 70/100-19 CST off-road mud tyre
DIMENSIONS
- Overall 1,860 x 780 x 1,050mm
- Seat Height 830mm
- Ground Clearance 270mm
- Wheel Base 1,255mm
WEIGHTS
-
N.W of Complete Bike 45 kg
- Max Loading 100 kg
